Methil

Navantia UK’s Methil facility is at the forefront of Scotland’s offshore renewables revolution.

Icono de Navantia en blanco

With a growing role in the fabrication of offshore wind components – including jackets, monopiles, substations and complex transition pieces – Methil is helping to drive the UK’s clean energy ambitions.

Following Navantia UK’s acquisition of Harland & Wolff’s facilities in early 2025, Methil is set to benefit from targeted investment to expand its fabrication capacity and enhance its industrial infrastructure. This development reinforces the site’s strategic importance in delivering large-scale energy infrastructure and supporting high-value manufacturing in Fife.

Methil’s work supports UK-wide goals for energy security, decarbonisation and industrial renewal, while also creating skilled employment in a key Scottish coastal economy.

Our dockyard

Methil main office

Main Offices

  • Fully equipped client, project and administration office facilities
Fabrication Shop 1

Fabrication Shop 1

  • Mainly used for the preparation of steel plates, tubulars and sections and for prefabrication work
  • Size: 26m (w) x 122m (l)
  • Door opening: 20m (w) x 9m (h)
  • 2 x 30t Goliath cranes
  • 2 x 10t Goliath cranes
Fabrication Shop 2

Fabrication Shop 2

  • Mainly used for sub-assembly of deck sections, PAV’s and node fabrication
  • Size: 26m (w) x 134m (l)
  • Door opening: 24m (w)x 12m (h)
  • 2 x 60t Anderson Grice overhead travelling crane: 26m span x 12m hoisting height
  • 2 x 20t overhead crane: 6m span x 12m hoisting height
Fabrication Shop 2

Fabrication Shop 3 – Main Assembley Hall

  • Mainly used for the final erection and fitting out of jackets modules and integrated decks. It is one of the largest final assembly halls in Europe
  • Size: 48m (w) x 134m (l) x 30m (h)
  • Door opening: 47m (w) x 29m (h)
  • 2 x 40t Carruthers overhead travelling cranes: 48m span x 30m hoisting height
  • 2 x auxiliary hoists
Main paint shop

Main Paint Shop

  • Fully equipped to shot blast and paint to standard offshore paint systems and thermal spray aluminium systems
  • Temperature controlled with ventilation and dust extraction systems
  • Size: 30m (w) x 55m (l)
  • Door opening: 28m (w) x 10m (h)
Shop 4 – Secondary Paint Shop

Shop 4 – Secondary Paint Shop

  • Size: 30m (w) x 60m (l)
  • Door opening: 28m (w) x 5.7m (h)
Methil main stores

Main Stores

  • Central store: 1,600m²
  • Client equipment parts stores: 1 x permanent portal frame building, 30m (w) x 60m (l)
Material Storage Area

Material Storage Area

  • Steel stockyard: 17,000m²
  • Material stockyard: 18,600m²
External Construction Site

External Construction Site

  • 5t crane
  • 40m slip
  • 8t electric winch
  • Spray booth

A. QUAYSIDE AREA – ACCESS TO:

  • Open construction area of 69,000m²
  • Concrete to load out and fabrication / assembly space
  • Even surface of consolidated colliery shale with a load bearing capacity of 30 te/m²
  • 24 -hour operation with floodlighting and with mains electricity distribution points throughout

B. QUAYSIDE AREA 2

  • Open construction area of 186,000m²

C. PRE FABRICATION FACILITY AREA 3

  • Open construction area of 17,000m²
Quayside

Quayside

  • Quay 2 (and access to Quay 1) with frontage, min. water depth and capacity
  • The load out quay can accommodate modular hydraulic tyred trailer units for load outs in excess of 22,000 tonnes
